Overview

The CR1000X is our flagship data logger that provides

measurement and control for a wide variety of applications. Its

reliability and ruggedness make it an excellent choice for

remote environmental applications, including weather

stations, mesonet systems, wind profiling, air quality

monitoring, hydrological systems, water quality monitoring,

and hydrometeorological stations.

The CR1000X is a low-powered device that measures sensors,

drives direct communication and telecommunications,

analyzes data, controls external devices, and stores data and

programs in onboard, nonvolatile storage. The electronics are

RF-shielded by a unique sealed, stainless-steel canister. A

battery-backed clock assures accurate timekeeping. The

onboard, BASIC-like programming language, common to all

contemporary Campbell Scientific data loggers, supports data

processing and analysis routines.

Benefits and Features

Operational in extreme environments with a standard

operating range of -40° to +70°C and an extended operating

range of -55° to +85°C

Connects directly to a computer's USB port

Captures quickly changing data values with fast analog

measurement capabilities (300+ Hz)

Differentiates even slight changes in data values with higher-

resolution measurements (24 bit Adc)

Includes two non-isolated current input channels for directly

connecting sensors with 0-to-20 mA or 4-to-20 mA current

outputs

Contains an onboard CPI port for hosting Campbell high-

speed sensors and distributed modules (CDM)

Directly connects to Ethernet

Includes microSD card drive for extended memory

requirements

Provides simple serial sensor integration and measurement

with SDI-12, RS-232, and/or RS-485

Supports full PakBus networking

Includes embedded web page for direct connection via web

browser

Detailed Description

The CR1000X is a low-powered device designed to measure sensors, drive direct communication and telecommunications,

Flagship Data

Logger

Accurate, rugged, reliable

Measurement and Control Datalogger

CR1000X

For comprehensive details, visit: www.campbellsci.com/cr1000x

analyze data, control external devices, and store data and

programs in on-board, non-volatile storage. The electronics are

RF-shielded and glitch-protected by a unique sealed, stainless-

steel canister. A battery-backed clock assures accurate

timekeeping. The on-board, BASIC-like programming language

—common to all Campbell Scientific data loggers—supports

data processing and analysis routines.

The CR1000X wiring panel includes twoswitchable 12 V

terminals, analog grounds dispersed among 16 analog

terminals, and unpluggable terminal blocks for quick

deployment.

Specifications

-NOTE- Additional specifications are listed

in the CR1000X Specifications

Sheet.

Operating Temperature

Range

-40° to +70°C (standard)

Non-condensing environment

-55° to +85°C (extended)

Maximum Scan Rate 1000 Hz

Case Material Anodized aluminum

Analog Inputs 16 single-ended or 8 differential

(individually configured). Two

analog inputs can measure 4 to 20

mA or 0 to 20 mA natively. Four

analog inputs can provide pulse/

digital I/O functions.

Pulse Counters 10 (P1 to P2 and C1 to C8)

Voltage Excitation Terminals4 (VX1 to VX4)

Maximum Source/Sink

Current

±40 mA (voltage excitation)

50 mA (switched regulated)

Communications Ports RS-422

Ethernet

USB Micro B

CS I/O

RS-232

CPI

RS-485

Data Storage Ports microSD

Switched 12 Volt 2 terminals

Digital I/O 8 terminals (C1 to C8) configurable

for digital input and output.

Includes status high/low, pulse

width modulation, external

interrupt, edge timing, switch

closure pulse counting, high-

frequency pulse counting, UART,

RS-232, RS-485, SDM, SDI-12, I2C,

and SPI function. Terminals are

configurable in pairs for 5 V or 3.3

V logic for some functions.

Input Limits ±5 V

Analog Voltage Accuracy ±(0.04% of measurement +

offset) at 0° to 40°C

±(0.06% of measurement +

offset) at -40° to +70°C

Accuracy specifications do not

include sensor or measurement

noise.

±(0.08% of measurement +

offset) at -55° to +85°C

(extended temperature range)

ADC 24-bit

Power Requirements 10 to 18 Vdc input (See manual for

further details.)

Real-Time Clock Accuracy ±3 min. per year (Optional GPS

correction to ±10 µs)

Internet Protocols Ethernet, PPP, RNDIS, ICMP/Ping,

Auto-IP (APIPA), IPv4, IPv6, UDP,

TCP, TLS (v1.2), DNS, DHCP, SLAAC,

Telnet, HTTP(S), SFTP, FTP(S), POP3/

TLS, NTP, SMTP/TLS, SNMPv3, CS I/

O IP, MQTT

Communications Protocols CPI, PakBus, SDM, SDI-12, Modbus,

TCP, DNP3, UDP, NTCIP, NMEA

0183, I2C, SPI, and others

Battery-backed SRAM for

CPU Usage & Final Storage

4 MB

Data Storage 4 MB SRAM + 72 MB flash (Storage

expansion of up to 16 GB with

removable microSD flash memory

card.)

Idle Current Drain, Typical < 1 mA (@ 12 Vdc)

Active Current Drain,

Typical

1 mA (1 Hz scan @ 12 Vdc)

Active Current Drain,

Average

55 mA (20 Hz scan @ 12 Vdc)

Dimensions 23.8 x 10.1 x 6.2 cm (9.4 x 4.0 x 2.4

in.)

Additional clearance required for

cables and leads.

Weight 0.86 kg (1.9 lb)
